Performance Built Dodge G56 Transmission Sale

Our Mercedes Benz G56 transmission was introduced in 2005 for use in Dodge Ram 2500 and 3500 series pickup trucks. The G56 six speed manual transmission replaced the NV5600, with higher power input it is capable of handling over 600lbs of torque.

The G56 transmission is much lighter with its aluminum case where the NV5600 transmission has a cast iron case. The G56 transmission has design upgrades implemented to resolve the oil feed issues that have been a constant point of interest with its predecessors.

Advanced Smart Parts Technology
A transmission designed by Mercedes deserves a certified team of builders that have been trained in the intricacies and precise tolerances of this German design. Our Smart Parts G56 is packed full of upgrades to make this already heavy duty transmission an even tougher work horse.

Common Names

Mercedes G56 Transmission
Dodge G56 Transmission

Original Manufacturer

Mercedes Benz

Dodge Vehicle Compatibility

Ram 2500
Ram 3500
1 Ton
3/4 Ton

Dodge G56 Transmission Years Of Use

2005.5
2006
2007
2008
2009
2010
2011

Performance Upgrades

Synchronizer
Seal & Gasket
Bearing
Self Lubricating Bearing Reservoir
Main Shaft
Dyno-Tested

G56 Build Type

Performance Grade remanufactured QS9000 Certified

Ordering
Details
Q&A

G56 Sale Price:	$3,295.00
List Price:	$3,995.00
Core Deposit:	$1500.00 ?
Delivery/Core Shipping:	Call for Quote
Sales Tax Applied	0%
5 Star product Rating:	★★★★★
PN: BG56P
Phone Order: 1-888-995-7278	Mon-Sun 8-9 CST

Cart

Buy

Warranty Info

G56 Transmission Applications For Dodge Ram Pickup Trucks

G56 Transmission Applications For Dodge Ram Pickup Trucks
Make	Engine Size	Year	Tag Number
Dodge 4X2	Ram 2500	2005-Present	5.7L Gas 5.9L Diesel 6.7L Diesel
Dodge 4X2	Ram 3500 Ram 4500	2005-Present	5.7L Gas 5.9L Diesel 6.7L Diesel

Make	Engine Size	Year	Tag Number
Dodge 4X4	Ram 2500	2005-Present	5.7L Gas 5.9L Diesel 6.7L Diesel
Dodge 4X4	Ram 3500 Ram 4500	2005-Present	5.7L Gas 5.9L Diesel 6.7L Diesel

G56 specs and current transmission Data
Original Manufacturer:	Mercedes Benz
Gears:	6 Speed Manual
Drive:	2WD and 4WD Available
Recommended G56 Oil / Fluid:	Synthetic ATF (Any Name Brand)
Torque Rating:	Manufacturer: HD 600 lb-ft Ours: HD 600 + lb-ft
G56 Transmission Oil capacity:	1 Gallon +
Weight:	225 lb Dry
Maximum GVW:	15,500 lb
G56 Build:	Performance Built
Performance Inspected For:	Leaks Shifting Difficulties Vibrations Excessive Noise Temperature and Performance
G56 Transmission Gear Ratios:	6.29 - First 3.48 - Second 2.10 - Third 1.38 - Fourth 1.00 - Fifth 0.79 - Sixth 6.29 - Reverse
Identification Number:	400-00450 400-00452 400-00453 400-00455
Hollander Interchange Numbers:	52104714AC 52104714AD 52104714AE 6.7L RL104714AA 52104715AC 52104715AE 52104717AC 52104718AC
Notes:	There is a minor difference in 6th gear ratio between thru '06 being 0.746 & '07 being 0.79

Questions And Answers About The G56 Transmission

December 15th, 2012

Question
How do I know if I have a NV5600 or G56 transmission?

Answer
The easiest way to distinguish between these transmissions is to check the date of your truck. A Dodge Ram 6 speed with the years 2004 and below will be a 5600. 2006 and up will be the G56. 2005 is the crossover year and a quick observation of the casing can answer your question. The g56 is cast out of aluminum and the 5600 will be cast iron.

Jimmy O**** Dallas, TX

If you have a question you would like to submit, please e-mail it to: info@smartpartsauto.com
