6L90 Vehicle Applications
| Make |
Model |
Year |
Engine Size |
| Chevy |
Camaro ZL1 |
2012-2013 |
V8 / 6.2L |
| Express 2500 |
2010-2013 |
V8 / 4.8L
V8 / 6.0L
V8 / 6.6L Diesel |
| Express 3500 |
2010-2013 |
| Silverado 1500 |
2012-2013 |
V8 / 6.0L |
| Silverado 2500 |
2012-2013 |
| Silverado 3500 |
2012-2013 |
| Silverado 1500SS |
2012-2013 |
| Silverado 2500HD |
2007-2013 |
| Silverado 3500HD |
2007-2013 |
| Suburban 1500HD |
2012-2013 |
| Suburban 2500HD |
2012-2013 |
| Tahoe |
2008-2013 |
| GMC |
Savana 2500 |
2010-2013 |
V8 / 4.8L
V8 / 6.0L
V8 / 6.6L Diesel |
| Savana 3500 |
2010-2013 |
| Sierra 1500 |
2012-2013 |
V8 / 6.0L |
| Sierra 2500 |
2012-2013 |
| Sierra 3500 |
2012-2013 |
| Sierra Denali |
2012-2013 |
| Sierra 2500HD |
2007-2013 |
| Sierra 3500HD |
2007-2013 |
| Yukon |
2008-2013 |
| 6L90 specs and current transmission Data |
| Original Manufacturer: |
General Motor Company |
| Gears: |
Automatic / 6 Speed |
| Drive: |
2WD and 4WD Available |
| Recommended GM 6L80 / 6L80E Oil / Fluid: |
Dexron VI
(Any Name Brand) |
| Torque Rating: |
Manufacturer: 430 lb ft
Ours: 430 + lb ft |
| 6L90 Oil capacity: |
6 Gallon + |
| Weight: |
229 lb Dry |
| New, Used, or Rebuilt: |
Complete Rebuild |
| Performance Inspected For: |
Leaks
Shifting Difficulties
Vibrations
Excessive Noise
Temperature and Performance |
| 6L90 Gear Ratios: |
4.027 - First
2.364 - Second
1.532 - Third
1.152 - Fourth
0.852 - Fifth
0.667 - Sixth
3.064 - Reverse |
| 6L90e Transmission Tag Numbers (2013 and Up Are Not Listed Yet) |
| Manufacturer Identification Numbers: |
2DSA
2DBA
2DCA
2D2A
2DHA
2DKA |
| GM part number: |
24256841
24257880
24250414
24250416
24250415 |
| Hollander Interchange Numbers: |
400-04780
400-04747
400-04748
400-04749
400-04750 |
Questions Answered About The 6L80E Transmission
Question
Is there a difference between the 6L90 and the 6L80 transmission?
Answer
Yes, the 6L90 transmission is considered the heavy duty version of the 6L80. The 6L90 transmission has stronger input gear sets, strengthened output gear sets and six pinion gears.
Trent ***********
Tampa, FL
Question
Is there any difference between the 6L90 and the 6L90E transmission?
Answer
There is no difference between the 6L90 and the 6L90E. Some people call it the 6L90 and others call it the 6L90E transmission.
Joe G****
Cleveland, OH
